Circular Saw Machine
Product Code : LSK-WWPT-10715
Circular Saw Machine (SKU LSK-WWPT-10715) is a table-mounted circular saw bench for wood cutting. A 14 in (355 mm) blade rises through a 30 x 32 in table and runs at 4000 RPM, driven by a 3 HP motor, so boards and panels can be ripped and cross-cut accurately. Carpentry trainees in ITI, polytechnic and TVET workshops use it as their main sawing machine. Science Lab Supplies, based in Ambala, India, offers the saw bench to institutes, tender contractors and distributors.
Specifications
All technical details of this saw bench sit in the table below. In short, it combines a 30 x 32 in (762 x 813 mm) table with a 14 in (355 mm) blade; the motor is rated 3 HP at 1440 RPM and the blade spindle turns at 4000 RPM for clean cuts in timber and boards.
| Specification | Value |
|---|---|
| SKU | LSK-WWPT-10715 |
| Application | Wood cutting |
| Blade size | 14 in / 355 mm |
| Table size | 30 x 32 in (762 x 813 mm) |
| Spindle speed | 4000 RPM |
| Motor power | 3 HP |
| Motor speed | 1440 RPM |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Circular Saw Machine
On a training course the circular saw bench is where trainees learn to rip timber along the grain, cross-cut to length and cut boards to width, using the fence, a mitre gauge and push sticks. It also shows how blade height, feed rate and grain direction affect cut quality.
- ITI Carpenter and Wood Work Technician trades: ripping and cross-cutting exercises.
- Furniture-making modules: cutting parts to size from sawn timber and boards, then smoothing them on a Belt Sander.
- Polytechnic carpentry shop practice in civil engineering diplomas, with sawdust handled by a Universal Dust Collector.
- TVET workshop equipment for construction and joinery programmes.
A 14 in blade at 4000 RPM can cause severe injury and kickback. Keep the riving knife and guard fitted, use push sticks near the blade and let only trained users operate the saw under supervision.
Standard Scope of Supply
The Circular Saw Machine is supplied as a single unit as described above, with its 30 x 32 in table, 14 in blade and 3 HP motor. Fences, extra blades and any other optional accessories you want with it are itemised and confirmed on the quotation.
Packing, MOQ and Lead Time
Quotations are prepared for one saw or for several to equip a full carpentry shop, stating the packing, delivery time and price for that quantity. Planers, moulders and other wood workshop machines can be added to the same quotation for vocational training centres.
As a registered exporter with an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Kenya, Ghana, Ethiopia, Tanzania, Uganda and the UAE. For a quotation on the 14 in saw bench, get in touch via the contact page or drop it into the enquiry cart; tender-led orders can use the lab tender page.
Frequently Asked Questions
What blade size does it use?
A 14 in (355 mm) circular blade, running at a spindle speed of 4000 RPM and rising through a 30 x 32 in table, which gives room to support boards and panels while they are cut.
Why do the motor and spindle speeds differ?
The 3 HP motor runs at 1440 RPM and drives the blade spindle up to 4000 RPM, giving a higher blade speed for cleaner cuts in wood.
Who supplies the Circular Saw Machine?
Science Lab Supplies supplies it from Ambala, India, as part of its wood workshop range for TVET, ITI and polytechnic training, and can put it on one quotation with planers, sanders and dust collection.
Can it cut metal?
No. The listed application is wood cutting. For metal bar and sections, see the band saw and power hacksaw machines in the TVET ranges, which are described for steel and copper stock.
