Chisel Mortise Machine
Product Code : LSK-WWPT-10718
Chisel Mortise Machine (SKU LSK-WWPT-10718), also called a hollow chisel mortiser, cuts square and rectangular mortises in timber. A drill bit turning inside a hollow square chisel clears the waste while the chisel squares the corners, so a clean mortise is made in one plunge. Joinery and furniture trainees in ITI, polytechnic and TVET workshops use it to make mortise-and-tenon joints. Supply to institutes, tender contractors and distributors is handled by Science Lab Supplies from Ambala, India.
Specifications
Every technical detail given for the mortiser is in the table below. In short, it has a 1 HP spindle motor running at 3,400 rpm, takes hollow chisels from 1/4 in to 3/4 in (about 6 to 19 mm), and its chuck holds up to 1-1/8 in (about 28.6 mm); table figures are listed as quoted.
| Specification | Value |
|---|---|
| SKU | LSK-WWPT-10718 |
| Also known as | Hollow chisel mortiser |
| Chisel range | 1/4 in to 3/4 in (approx. 6–19 mm) |
| Spindle motor | 1 HP |
| Spindle speed | 3,400 rpm |
| Chuck capacity | 1-1/8 in (approx. 28.6 mm) |
| Table (as listed) | 12-1/2 in to 21-1/4 in |
| Tilting table (as listed) | 300 mm |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Chisel Mortise Machine
The chisel mortise machine lets trainees cut accurate, repeatable mortises for frames, doors, chairs and tables far faster than by hand. Exercises cover marking out, choosing a chisel to match the tenon, setting depth stops, clamping the work and checking the fit of the finished joint.
- ITI Carpenter and Wood Work Technician trades: mortise-and-tenon joint exercises.
- Door and window frame modules: through and stopped mortises in stiles brought to size on the Combination Surface Planer and Thicknesser.
- Furniture-making courses: leg-and-rail joints for tables and chairs, with legs shaped on the Wood Turning Lathe Machine.
- TVET workshop equipment for joinery and cabinet-making programmes.
Always clamp the workpiece, keep fingers away from the chisel and bit, and switch off before changing chisels. Operate under instructor supervision.
Standard Scope of Supply
The Chisel Mortise Machine is supplied as a single unit as described above, with its 1 HP spindle motor and chuck. The hollow chisels and bits supplied with it, chosen from the 1/4 to 3/4 in range, are itemised and confirmed on the quotation.
Packing, MOQ and Lead Time
Quotations can be for a single mortiser or a set for a whole joinery shop, and each states packing, delivery time and price for the quantity. Tenoning, dovetail and dowelling machines, plus spare hollow chisels, can be added to the same quotation for a complete joinery bench.
As a registered exporter with an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Tanzania, Uganda, the UAE, Saudi Arabia, Oman and the Philippines. To have the hollow chisel mortiser quoted, reach out on the contact page or note it in the enquiry cart; tender submissions are covered by the lab tender page.
Frequently Asked Questions
What size mortises can it cut?
It takes hollow chisels from 1/4 in to 3/4 in (about 6 to 19 mm) wide; longer mortises are made by overlapping successive cuts along the marked line.
How does a hollow chisel mortiser work?
A bit rotating at 3,400 rpm inside a square hollow chisel bores out the waste while the chisel edges pare the corners square as the head is lowered.
Who supplies the Chisel Mortise Machine?
Science Lab Supplies supplies it from Ambala, India, as a TVET lab equipment supplier for carpentry and joinery workshops, and can quote it with tenoning, dovetail and dowelling equipment on one enquiry.
What table size does it have?
The specification lists the table as 12-1/2 in to 21-1/4 in and a tilting table figure of 300 mm. Ask through the contact page and the quotation will confirm the exact table size for the model offered.
