Thread Gauge
Product Code : LSK-MMTM-10603
Thread Gauge (SKU LSK-MMTM-10603) is a hand inspection gauge for checking screw threads during mechanical and machining work. Trainees in fitting, turning and machinist courses use it to confirm that a thread they have cut, or a bolt they have been handed, matches the required form. Buyers can order it from Science Lab Supplies, which sends it out of Ambala, India to polytechnics, ITI centres, engineering colleges, tender contractors and distributors as TVET workshop equipment.
Specifications
The table gives every detail of this screw-thread gauge. In brief, it is made from quality-tested, corrosion-resistant material meant for long service in a workshop, where it may meet cutting oil and coolant, and it is offered in different specifications, so the thread series, pitch range or gauge type is agreed at enquiry.
| Specification | Value |
|---|---|
| SKU | LSK-MMTM-10603 |
| Type | Thread gauge for checking screw threads |
| Material | Quality-tested raw material |
| Corrosion resistance | Corrosion resistant |
| Service life | Long lasting |
| Specification | Available in different specifications as per requirement |
| Use | Mechanical works |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Thread Gauge
In a training workshop the gauge is used to identify an unknown thread and to check threads produced on the lathe or with taps and dies. Learners compare the gauge against the thread and look for light between the flanks, which builds the inspection habit expected in fitter and machinist work.
- ITI Fitter trade: identifying and checking threads on fasteners during assembly exercises.
- ITI Turner and Machinist trades: checking screw threads cut with a Threading Tool Holder on a centre lathe.
- Diploma and B.Tech workshop technology: introducing thread terminology and measurement.
- TVET mechanical modules: inspecting external threads and holes tapped on an Upright Drilling Machine.
Standard Scope of Supply
The Thread Gauge is supplied as a single unit as described above, in the specification agreed on your order. Please state the thread series or pitch range you need when you enquire; any optional accessories or companion gauges are listed on the quotation.
Packing, MOQ and Lead Time
Order a single gauge for a teacher's bench or one per trainee for a whole fitting section; either way the quotation sets out packing, delivery time and price for that quantity. Related workshop tools for technical training institutes can be added to the same document.
With an Importer-Exporter Code, Science Lab Supplies is a registered exporter and can ship to buyers in Iraq, Nigeria, Kenya, Ghana, Ethiopia and Tanzania. Post the thread series you need through the contact page, drop the gauge into the enquiry cart beside other tools, or follow the lab tender page for bid supply.
Frequently Asked Questions
What does a thread gauge check?
It checks screw threads, letting a trainee or inspector confirm that a bolt, stud or tapped hole matches the required thread before parts are assembled.
Which specification will I receive?
The gauge is offered in different specifications as per requirement. State the thread series and pitch range, or send your tender wording, and the quotation will describe the exact gauge offered.
Who supplies the Thread Gauge?
Science Lab Supplies, an Ambala-based supplier in India, offers the gauge to training institutes, colleges, workshop contractors and distributors, and can list it beside lathe, drilling and fitting-shop items on one quotation.
Does the gauge resist rust in the workshop?
Yes. It is made from a corrosion-resistant material, which suits workshops where tools meet cutting fluid. Wiping and storing it dry after use still keeps it in good condition.
Related Thread-Cutting and Measuring Tools
A thread gauge is most useful alongside the tools that produce threads and the instruments that measure other dimensions. These six items cover screw-cutting setup, power tapping and precision measurement, so the inspection bench of a fitting or turning section can be equipped from one quotation.
- Center Gauge — etched graduations in 14ths, 20ths, 24ths and 32nds of an inch for counting threads per inch.
- Center Lathe Machine — cuts metric threads of 1 to 6 mm pitch and inch threads of 2 to 24 TPI.
- Feeler Gauge — 25 stainless steel blades from 0.04 to 1.00 mm, folding into a metal case.
- Radial Drilling Machine — engages taps shock-free through a clutch and reverses the spindle to withdraw them.
- Vernier Caliper — 0.01 mm resolution for outside, inside and depth measurements, in hardened stainless steel.
- Digital Micrometer — 0 to 25 mm range at 0.01 mm resolution, with an LCD reading in inch and metric units.
