Industrial Hydraulics Training Equipment
Product Code : LSK-HAP-10575
Industrial Hydraulics Training Equipment (SKU LSK-HAP-10575) is a large universal testing frame in which a single- or double-acting hydraulic ram carriage applies load to test specimens set up between twinned steel channels. It serves structural and hydraulic loading practicals in civil and mechanical engineering colleges, polytechnics and TVET institutes. Each frame is manufactured by Science Lab Supplies in Saha, Ambala, India (Plot 448, HSIIDC Industrial Area), and quotations go from that factory straight to institutions, contractors and distributors.
Specifications
The table gives the frame’s dimensions and fittings one per row. In short, a twinned steel channel structure 4.61 m long, 2.53 m high and 1.2 m wide offers a 4.0 × 1.6 m working space, carries the hydraulic ram carriage on its top channels and stands on four anti-vibration levelling feet.
| Specification | Value |
|---|---|
| SKU | LSK-HAP-10575 |
| Frame type | Universal testing frame |
| Construction | Twinned steel channel |
| Fixings | High tensile |
| Ram carriage | Single- or double-acting hydraulic ram, carried on the top channel members |
| Overall length | 4.61 m |
| Overall height | 2.53 m |
| Overall width | 1.2 m |
| Working space | 4.0 m long × 1.6 m high |
| Spacing between verticals | 0.60 m, for wide test specimens |
| Dial gauge support | Set of hollow steel support bars |
| Specimen accessories | For quick set-up in a variety of arrangements |
| Self-weight | About 1 tonne |
| Feet | 4 anti-vibration levelling feet |
| Manufacturer | Science Lab Supplies, Saha, Ambala, Haryana |
| Country of origin | India |
Applications and Experiments for the Industrial Hydraulics Test Frame
Trainees mount a specimen in the working space, apply load through the hydraulic ram and record deflections from dial gauges held on the support bars, linking hydraulic actuation to structural behaviour. Despite its name, it is a structural testing frame rather than a hydraulic circuit trainer, serving as TVET workshop equipment for structures, strength of materials and hydraulic loading practicals.
- Civil engineering degree and diploma labs: load and deflection tests on wide specimens, using the 0.60 m spacing between verticals.
- Structures practicals: setting up specimens in different support arrangements with the frame accessories.
- Fluid power topics: how a ram turns hydraulic pressure into test load, compared with the bench-scale Universal Testing Machine and the load-cell Beam Apparatus.
The frame weighs about 1 tonne and the ram applies large forces: level it on its feet, keep clear of loaded specimens and run every test under instructor supervision.
Standard Scope of Supply
The supply covers the twinned steel channel frame with its high tensile fixings, the hydraulic ram carriage in single- or double-acting form, the specimen set-up accessories, a set of hollow steel dial gauge support bars and the four levelling feet. Dial gauges, specimens and the hydraulic power source are confirmed on the quotation.
Packing, MOQ and Lead Time
A single frame or several for a structures laboratory can be quoted. The quotation states packing, delivery time and price for exactly that quantity, and beam, stiffness or other material testing apparatus can be included in the same document if you need it.
As a registered exporter with an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Qatar, Sri Lanka, Vietnam, Malaysia, Peru and Egypt. Send the specimen sizes you plan to test through the contact page, shortlist the frame in the enquiry cart, or check the lab tender page if the purchase runs through a formal tender.
Frequently Asked Questions
What is the working space of the frame?
The working space is 4.0 m long and 1.6 m high inside an overall structure of 4.61 × 2.53 × 1.2 m, and the verticals are spaced 0.60 m apart so that wide test specimens fit.
Is the ram single- or double-acting?
The top channel members carry a hydraulic ram carriage in either a single-acting or a double-acting version. State which one you need when you enquire and the quotation will list it.
Is Science Lab Supplies the manufacturer?
Yes. The frame is manufactured at the company’s Saha, Ambala factory in India, so specification questions, quantities and delivery are handled directly with the maker itself.
What safety precautions apply?
Treat the ram and hoses as pressurised until the system is shut down and relieved, keep hands clear of loaded specimens, wear eye protection and work under supervision on the levelled frame.
