CNC Milling Machine with Cabinet and PC
Product Code : LSK-CTM-10795
CNC Milling Machine with Cabinet and PC (SKU LSK-CTM-10795) is a bench-scale three-axis CNC mill delivered as a complete workstation: the machine, a cabinet that houses the computer, controller and wiring, and a PC for programming. It accepts standard G-code, so CAM output can go straight to the machine. Science Lab Supplies handles orders for it from Ambala, India, serving ITIs, polytechnics, engineering colleges and tender contractors.
Specifications
The rows below list every published detail of this milling workstation. In short, travel is 300 mm on X, 146 mm on Y and 153 mm on Z through 20-pitch Cr-Mo leadscrews with split bronze nuts, ground steel ways carry a hard-anodised aluminium table, and the spindle runs from 1100 to 11000 rpm.
| Specification | Value |
|---|---|
| SKU | LSK-CTM-10795 |
| X travel | 300 mm |
| Y travel | 146 mm |
| Z travel | 153 mm |
| Spindle speed | 1100–11000 rpm |
| Stepping resolution | 0.003 mm |
| Mechanical repeatability | 0.01 mm |
| Rapid travel | 30 in/min |
| Leadscrews | 1/2 in (12.7 mm), 20 pitch, Cr-Mo, on all axes |
| Leadscrew nuts | Adjustable split bronze nuts |
| Slideways | Ground steel sliding ways with adjustable brass gib |
| X-axis gib | Adjustable tapered brass gib |
| Table | Hard-anodised aluminium |
| Programming | Universal standard G-code import |
| Coolant | Coolant system with removable collector |
| Cabinet | Bottom storage for computer, controller and wiring |
| PC processor | 2.4 GHz desktop processor |
| PC memory | 512 MB RAM |
| Optical drive | 52X DVD writer |
| Monitor | 15 in TFT |
| Input devices | Keyboard and optical mouse |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the CNC Milling Machine
Trainees use the workstation to write or import G-code, prove it on the PC and then mill slots, pockets and profiles in practice material. Its compact travel suits CNC programming classes where many students need machine time, and the cabinet keeps the computer and wiring tidy at each station.
- ITI Machinist and CNC operator courses: three-axis milling exercises, progressing later to automatic tool changing on the CNC Semi Production Mill.
- Diploma and B.Tech CAD/CAM labs: running G-code generated from CAM software, with turning taught on the CNC Lathe System.
- Production engineering: milling cutting forces are measured in a separate experiment with the Milling Tool dynamometer on a milling machine with automatic feed.
Close the guard while cutting and supervise trainees at all times.
Standard Scope of Supply
Each set comprises the CNC milling machine, its coolant system with removable collector, the storage cabinet with controller and wiring, and a PC with monitor, keyboard, mouse and DVD writer. Because computer hardware changes quickly, the quotation confirms the exact PC configuration supplied.
Packing, MOQ and Lead Time
Request a quotation for one workstation or a full row of vocational training equipment for a CNC classroom; it will state the packing, delivery time and price for that quantity. Cutters, vices or a CNC lathe from the same range can go on the same quotation.
As a registered exporter with an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Qatar, Sri Lanka, Vietnam, Malaysia, Peru and Egypt. For a CNC classroom budget, state the number of stations on the contact page, keep a running list in the enquiry cart, or see how tender supply works on the lab tender page.
Frequently Asked Questions
What is included with the CNC Milling Machine with Cabinet and PC?
The mill, its coolant system, a cabinet holding the controller and wiring, and a PC with monitor, keyboard and mouse. It arrives as a ready workstation rather than a bare machine.
Can it run programs from CAM software?
Yes. It imports universal standard G-code, so programs produced by CAM software or written by hand can be loaded from the PC and run on the machine.
Who supplies this CNC milling machine?
Science Lab Supplies provides the complete workstation from Ambala, India, and quotes it to training institutes, colleges and contractors that are setting up CNC labs.
What accuracy does it offer?
Stepping resolution is 0.003 mm and mechanical repeatability is 0.01 mm, which suits teaching part programming, work setting and the measurement of milled parts in a training lab.
Related CNC and Conventional Milling Equipment
A CNC milling lab can combine machine sizes and control options. These items from the CNC Trainer Machine and Metal Manufacturing Training Machine ranges add desktop, table, floor and conventional mills plus controls, and any of them can share this quotation.
- CNC Micro Mill — desktop system with the same 300 x 146 x 153 mm travel and a 1/4 HP spindle motor.
- CNC Milling Machine Table Model — 400 x 145 mm worktable with three T-slots and a 100–7000 rpm spindle.
- CNC Milling Machine Floor Model — 500 x 160 mm worktable rated for 35 kg and a 1 kW spindle motor.
- CNC Trainer Milling Machine — 200 x 600 mm table, 3 HP spindle and a PC-based controller.
- CNC Milling Controller — six-axis control with USB and Ethernet links and G-code track preview.
- CNC Retrofitting Kit for Milling Machine — converts a milling machine to CNC and imports DXF, BMP, JPG and HPGL files.
- 8 Directional Vertical Milling — 70 x 330 mm table with 70–2800 rpm electronic speed control.
- Universal Milling Machine — conventional mill with a 1150 x 255 mm working surface.
