Milling Tool
Product Code : LSK-TOMLE-10627
Milling Tool (SKU LSK-TOMLE-10627) is a three-component milling dynamometer: a strain-gauged sensing unit and a digital indicator that together show the cutting forces in three directions while a milling machine is cutting. Students use it to see how depth of cut, feed, speed and material change those forces. Science Lab Supplies supplies it from Ambala, India to engineering colleges, polytechnics, tender contractors and distributors.
Specifications
The mechanical sensing unit, 300 x 300 mm overall, holds octagonal rings with strain gauges sandwiched between two mild-steel plates. A three-channel digital force indicator with balancing potentiometers and a polycarbonate front plate displays all three forces at once, each over a range of 0 to 500 kg.
| Parameter | Value |
|---|---|
| SKU | LSK-TOMLE-10627 |
| Sensing principle | Octagonal rings with strain gauges |
| Sensing unit | Rings between two M.S. plates; 300 x 300 mm overall |
| Force range | 0–500 kg in each coordinate direction (about 4.9 kN) |
| Indicator | 3-channel digital, balancing potentiometers, polycarbonate front plate |
| Services required | Milling machine with automatic feed and tooling; 230 V, single phase, 50 Hz stabilised supply |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Milling Tool Dynamometer
With the sensing unit set up on the milling machine, students take cuts at different depths, feeds and speeds and read the three force components simultaneously. Plotting force against each parameter shows how cutting conditions and work material drive tool load and power in milling.
- B.Tech/B.E. production engineering: measurement of milling forces in three directions.
- Machining science: effect of depth of cut, feed and speed on cutting forces.
- Diploma mechanical engineering: strain-gauge force measurement in practice.
- Vocational training equipment for TVET machining modules.
The listing credits the set-up to another firm and names the product simply "Milling Tool"; it is a milling force dynamometer, not a cutter.
Standard Scope of Supply
Each set comprises the mechanical sensing unit with its octagonal rings and strain gauges between M.S. plates, and the three-channel digital force indicator. Not included: the milling machine with automatic feed and its tooling, which the laboratory provides.
Packing, MOQ and Lead Time
Quotations can be issued for one dynamometer or for a set covering milling, turning, drilling and grinding, with packing, delivery time and price stated for the quantity. Science Lab Supplies, as a TVET lab equipment supplier, can put the other versions on the same quotation.
As a registered exporter with an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Kenya, Ghana, Ethiopia, Tanzania, Uganda and the UAE. Enquire on the contact page, use the enquiry cart, or visit the lab tender page for tender supply.
Frequently Asked Questions
What does the Milling Tool measure?
It measures the cutting force in three coordinate directions during milling, each over 0 to 500 kg, shown together on a three-channel digital indicator.
Is a milling machine included?
No. The service requirements list a milling machine with automatic feed and tooling, plus a 230 V, single-phase, 50 Hz stabilised supply.
Who supplies the Milling Tool dynamometer?
Science Lab Supplies supplies it from Ambala, India to colleges, polytechnics and contractors equipping metal-cutting labs.
How do octagonal rings measure force?
Cutting forces slightly deform the rings, and the strain gauges fixed on them convert that strain into electrical signals, which the indicator displays as force.
