Grinder Tool
Product Code : LSK-TOMLE-10628
Grinder Tool (SKU LSK-TOMLE-10628) is a grinding tool dynamometer: a strain-gauge sensing unit and a two-channel digital force indicator that measure the forces produced while a surface grinder removes metal. Mechanical engineering students use it in metal-cutting and tool-design practicals to study real cutting forces. Science Lab Supplies supplies the unit from Ambala, India to engineering colleges, polytechnics, training institutes, tender contractors and distributors.
Specifications
The dynamometer works on the octagonal ring method. Two strain-gauged octagonal rings in a rigid, compact sensing unit carry the grinding load, and the two-channel digital indicator shows both force components at once, with balancing potentiometers for setting each channel before a run.
| Parameter | Value |
|---|---|
| SKU | LSK-TOMLE-10628 |
| Type | Strain-gauge grinding tool dynamometer, octagonal ring method |
| Sensing unit | Mechanical unit with two octagonal rings and strain gauges |
| Force range | 0–200 kg in each coordinate direction |
| Indicator | Two-channel digital force indicator with balancing potentiometers and polycarbonate front plate |
| Mechanical unit size | 300 x 300 mm overall |
| Services required | Surface grinding machine; 230 V, single phase, 50 Hz stabilised power supply |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Grinder Tool Dynamometer
This dynamometer measures the two force components generated during surface grinding and shows how they respond to depth of cut, feed, speed and work material. It fits metal-cutting practicals in B.Tech and diploma mechanical engineering and demonstrations in vocational training equipment programmes for machining.
- B.Tech / B.E. mechanical engineering: grinding-force measurement in the metal-cutting laboratory.
- Diploma mechanical engineering: machine-tool practicals on a surface grinder.
- Plotting how each cutting parameter changes the two measured forces.
- ITI and TVET machining courses: instructor-led demonstrations.
Standard Scope of Supply
Each set comprises the mechanical sensing unit with its two strain-gauged octagonal rings and the two-channel digital force indicator with balancing potentiometers and polycarbonate front plate. Not included: the surface grinding machine and the 230 V stabilised power supply, which the laboratory provides.
Packing, MOQ and Lead Time
Quotations can cover a single dynamometer or several units for a complete machine-tool laboratory, and each one sets out the packing, delivery time and price for the quantity requested. The lathe, drilling and milling dynamometers from this range can join the same quotation for a full TVET workshop equipment list.
As a registered exporter holding an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Ghana, Ethiopia, Tanzania, Uganda, the UAE and Saudi Arabia. To start an enquiry, write through the contact page or add this item to the enquiry cart; tender buyers can also use the lab tender page.
Frequently Asked Questions
What does the Grinder Tool measure?
It measures two force components during surface grinding, up to 200 kg in each coordinate direction, using strain-gauged octagonal rings. Both readings appear together on the digital indicator, so students can compare them for each set of cutting conditions.
What is needed to run this dynamometer?
A surface grinding machine and a 230 V, single-phase, 50 Hz stabilised power supply. Neither is part of the set; both are provided by the laboratory that installs the unit.
Who supplies the Grinder Tool?
Science Lab Supplies supplies it from Ambala, India. Colleges and training institutes can buy directly, and tender contractors and distributors receive the same item-wise quotation.
Can it be quoted for a college or TVET tender?
Yes. Share the tender specification, quantity and delivery location, and an item-wise quotation will be prepared against the facts listed above.
Related Tool Dynamometers
A metal-cutting laboratory usually measures forces on more than one machine tool. These items from the Theory of Machine range cover turning, drilling and milling, so students can compare force behaviour across processes, and all of them can be quoted with the grinding dynamometer.
- Tool Dynamometers — the dynamometer family for machining practicals.
- Lathe Tool — two-component dynamometer for turning, range 0–500 kg.
- Drilling Tool — thrust and torque measurement while drilling.
- Milling Tool — companion unit from the same range for milling practicals.
