Flexible Manufacturing System
Product Code : LSK-CTM-10785
Flexible Manufacturing System (SKU LSK-CTM-10785) is a CNC training system for teaching how automated, PLC-controlled machining works in a flexible manufacturing environment. Its listed machining unit is a servo-driven slant-bed CNC lathe with a hydraulic chuck and an automatic 8-station turret. Engineering colleges, polytechnics and TVET automation centres use it for manufacturing automation courses. From its base in Ambala, India, Science Lab Supplies supplies the system to institutes, contractors and distributors.
Specifications
The specification describes a PLC-based control system running with Cut Viewer software, servo motors with servo drives, a 45-degree slant bed and a 125 mm hydraulic chuck. A 2 HP AC servo spindle runs 100 to 3000 RPM through a VFD, with automatic coolant and lubrication.
| Parameter | Value |
|---|---|
| SKU | LSK-CTM-10785 |
| Controller; control system | Cut Viewer; PLC based |
| Axis motor and drive | Servo motors with servo drives |
| Bed; chuck | 45° slant; hydraulic, 125 mm |
| Centre height | 100 mm |
| Travel X / Z; feed rate | 80 / 280 mm; 0–10,000 mm/min |
| Resolution X and Z | 0.001 mm |
| Positional accuracy; repeatability | 0.005 mm; 0.010 mm |
| Spindle | AC servo, 2 HP, 100–3000 RPM with VFD |
| Tool changer | Automatic, 8-station turret |
| Accessories | Automatic coolant, automatic lubrication |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Flexible Manufacturing System
The system is used to show how a CNC machine is run automatically by a PLC: the hydraulic chuck, turret and coolant respond to control signals, so students see machining as one step in an automated sequence. It supports manufacturing automation, mechatronics and CNC programming practicals.
- B.E./B.Tech mechanical, production and mechatronics labs: FMS and automated machining concepts.
- Diploma in mechatronics or production engineering: PLC-controlled machining sequences.
- ITI mechatronics and advanced machine tool trades: automatic chucking and tool indexing.
- TVET automation modules: linking CNC machines with robots and PLC trainers.
Standard Scope of Supply
The system is supplied as described in the specification: the PLC-controlled, servo-driven CNC turning unit with hydraulic chuck, 8-station turret, Cut Viewer software and automatic coolant and lubrication. Any further cell elements, such as a robot or material-handling units, are listed separately on the quotation if you ask for them.
Packing, MOQ and Lead Time
You can ask for a quotation for a single system or for a complete automation lab. Each quotation states the packing, delivery time and price for the quantity, and robots, PLC trainers or other vocational training equipment can be added to it.
As a registered exporter with an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Uganda, the UAE, Saudi Arabia, Oman, the Philippines and Nepal. Tell us about your automation lab through the contact page, or build a list in the enquiry cart; buyers following a tender process can visit the lab tender page.
Frequently Asked Questions
What machine does this system use?
The listed specification is a servo-driven CNC lathe with a 45-degree slant bed, 125 mm hydraulic chuck, 2 HP spindle and automatic 8-station turret under PLC-based control.
Which elements of a full FMS cell are included?
The specification covers the CNC turning unit and its control. Tell us which other cell elements you need, and they will be itemised on the quotation.
Who supplies the Flexible Manufacturing System?
Science Lab Supplies supplies it from Ambala, India, and quotes it for engineering colleges, TVET centres, contractors and distributors.
What precautions apply during automatic cycles?
The chuck and turret move under program control, so keep guards closed, stay clear of moving parts and run cycles only under instructor supervision.
Related Automation and CNC Trainers
These four trainers extend the system into a full automation lab: a robotic arm for part handling, a PLC and HMI kit for control programming, a CNC lathe trainer listed as FMS compatible and a semi-production mill for prismatic parts. All can be placed on one quotation.
- Robotic Arm — five-joint robot for loading and handling tasks.
- PLC and HMI Training Kit — control and operator-panel practice.
- CNC Lathe Trainer Stepper — stepper lathe with FMS compatibility.
- CNC Semi Production Mill — servo mill with tool changer.
Browse the full CNC Trainer Machine range or all TVET lab equipment.
