Inclined Plane Brass
Product Code : LSK-AM-11099
Inclined Plane Brass (SKU LSK-AM-11099) is a hinged glass-topped board that can be set and clamped at any angle up to 45 degrees, with a pulley, brass roller, cart and pan for studying forces along a slope. It serves the Class 11 inclined plane practical and friction lessons in schools and introductory mechanics in colleges. Science Lab Supplies manufactures this model in its factory at Plot 448, HSIIDC Industrial Area, Saha, Ambala, India, and sells directly to schools, colleges, contractors and distributors.
Specifications
A 15 x 60 cm wooden board with a glass top is hinged on an iron base fitted with a sector carrying a graduated arc and a vertical scale. A 5 cm frictionless pulley attaches to the end of the plane by a clamp that can be adjusted to any necessary position.
| Parameter | Value |
|---|---|
| SKU | LSK-AM-11099 |
| Plane | Wooden board 15 x 60 cm with glass top |
| Base | Iron, with sector, graduated arc and vertical scale |
| Angle range | Clamps at any angle up to 45 degrees |
| Pulley | 5 cm, frictionless, on adjustable clamp |
| Accessories | Brass roller, cart and pan |
| Weights | Not included |
| Manufacturer | Science Lab Supplies, Saha, Ambala, Haryana |
| Country of origin | India |
Applications and Experiments for the Inclined Plane Brass
The plane is used to find the force needed to hold a roller or cart on a slope and to relate it to the angle of inclination. It supports the NCERT Class 11 physics experiment on the downward force along an inclined plane, plus friction and simple machine work in school and diploma mechanics.
- Class 11 physics: downward force along an inclined plane on a roller and its relation to the angle.
- Resolving the weight of a body into components along and normal to the plane.
- Measuring the angle of repose and the coefficient of friction between surfaces.
Standard Scope of Supply
The apparatus is complete with the glass-topped board hinged on its iron base with graduated sector and vertical scale, the 5 cm pulley on its adjustable clamp, a brass roller, a cart and a pan. Weights are not included in the set.
Packing, MOQ and Lead Time
Quote requests can be for one inclined plane or for enough units for every group in a school lab. The quotation lists packing, delivery time and price for your quantity, and a weight box or other school physics lab equipment in India can be included in the same reply.
Science Lab Supplies holds an Importer-Exporter Code, so it can ship to buyers in Bangladesh, Zambia, Rwanda, South Africa, Qatar and Sri Lanka. For an enquiry, use the contact page or add products to the enquiry cart; institutions buying by tender can refer to the lab tender page.
Frequently Asked Questions
What angles can the plane be set to?
The hinged board can be clamped at any angle up to 45 degrees. The angle is read on the graduated arc of the sector, and the vertical scale on the base gives the height of the plane.
What accessories come with the Inclined Plane Brass?
It comes with a brass roller, a cart and a pan, plus a 5 cm frictionless pulley on an adjustable clamp. Weights are not supplied and can be quoted separately.
Can the pulley be repositioned?
Yes. The 5 cm frictionless pulley is fixed to the end of the plane with a clamp that can be adjusted to any necessary position, so the cord can be lined up for each angle used.
Is the inclined plane manufactured by Science Lab Supplies?
Yes. Science Lab Supplies produces this brass-fitted inclined plane in its own Saha, Ambala factory in India, and each quotation comes directly from the manufacturer.
