Optics Set OW1, Wave Optics
Product Code : SCL-PL-12302
Optics Set OW1, Wave Optics (SKU SCL-PL-12302) is a boxed set for 14 optics experiments, from shadow formation and the camera to microscopes, telescopes, vision defects and prism spectra, carried out together with the OG1 set. It suits secondary and senior secondary optics teaching. Science Lab Supplies in Ambala, India, prices OW1 for schools, colleges, training institutes, tender contractors and distributors, on its own or with OG1.
Specifications
The OW1 contents are split into single rows in the table below. In short, four lenses in holders, a concave mirror, screens, diaphragms, a diffraction grating, polarization filters and a hollow prism sit in a foam-lined case, and they mount on a 1000 mm universal rail offered with the ME2 set.
| Specification | Value |
|---|---|
| SKU | SCL-PL-12302 |
| Experiments | 14, carried out in combination with the OG1 set |
| Support rod | 10 cm |
| Screens | White screen with scale; transparent screen |
| Converging lenses | +50, +100 and +300, each in a holder |
| Diverging lens | −100, in lens holder |
| Mirror | Concave mirror in holder |
| Holders | Single lens holder; lens holder plus slide holder; transparent holder |
| Shaped diaphragms | F-shaped; square hole |
| Hole diaphragms | 4 mm, 2 mm and 1 mm |
| Slit diaphragms | Slit; double slit |
| Grating | Optical diffraction grating |
| Polarisation | Polarization filters |
| Colour filter | Red filter in holder |
| Mounting parts | Threaded spindle; single rider; jumper with slot; jumper with screw |
| Ampoule support | Support block for 2 ampoules |
| Models | Raindrop model; hollow prism |
| Tool | Spatula |
| Literature | OW1 student workbook and teacher’s manual, in electronic form |
| Case | Captive lid, hinged handle, bayonet lock, foam insert with pre-formed compartments |
| Required rail | Universal rail, 1000 mm (offered with the ME2 set) |
| Other required accessories | Low-voltage power supply; square with protractor, 160 mm (OG1 accessories) |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the OW1 Optics Set
Used with OG1, the set moves a class from basic ray optics to optical instruments, the eye and spectra. A camera, magnifier, microscope and telescopes can be built on the rail and vision defects studied, which suits Class 10 and Class 12 optics and first-year college demonstrations.
- Class 10 science: the human eye and vision defects, set beside the Eye in Orbit, Magnified 5 Times, in 7 Parts model; prism spectra and rainbows, compared with a 50 mm Glass Prism (Equilateral, 50 × 50 mm).
- Class 12 physics: real and virtual images from concave mirrors and converging lenses.
- Class 12 physics: optical instruments, including the magnifying glass, microscopes, Galileo’s telescope and a mirror telescope.
- Shadow formation, stereoscopic vision and the concentration of a sugar solution.
Standard Scope of Supply
The case holds all the lenses, mirror, screens, diaphragms, holders, wave optics parts and literature listed in the table above, in a foam insert. The 1000 mm universal rail, the low-voltage power supply and the square with protractor are required accessories from the ME2 and OG1 sets, or quoted separately.
Packing, MOQ and Lead Time
Ask Science Lab Supplies to quote OW1 alone or with OG1 and the rail; the quotation lists packing, delivery time and price for that combination and for the number of sets you need. Other optics lab equipment for schools can be added.
Registered as an exporter with an Importer-Exporter Code, Science Lab Supplies is able to ship to buyers in Tanzania, Uganda, the UAE, Saudi Arabia, Oman and the Philippines. To have OW1 costed with or without its companion sets, write in on the contact page, compile the order in the enquiry cart, or open a tender enquiry via the lab tender page.
Frequently Asked Questions
Does OW1 work on its own?
Its 14 experiments are carried out with the OG1 set. The universal rail is offered with the ME2 set, and the power supply and square are OG1 accessories.
What instruments can students build with it?
They can set up the camera, a magnifying glass, microscopes, Galileo’s telescope and a mirror telescope, using the four lenses and the concave mirror in holders.
Does the set include wave optics components?
Yes. It includes a double-slit diaphragm, a slit diaphragm, an optical diffraction grating and polarization filters, along with a hollow prism for producing spectra.
Who supplies the Optics Set OW1?
A quotation for OW1 is prepared by Science Lab Supplies, a physics instruments supplier in India working from Ambala, and can list it alone or together with OG1, the ME2 set or separate optics items.
Related Optics Sets and Accessories
OW1 is designed to run alongside other sets, so these items belong on the same quotation: OG1 for the optics it builds on, ME2 for the universal rail, gratings and polarizers for wave optics, and a track system and spectrometer for further work.
- Optics Set OG1, Geometrical Optics — experimental lamp with a spare 12 V/20 W halogen bulb.
- ME2 Mechanical Box, Forces — 13 force experiments in a bayonet-locking case.
- Diffraction Gratings with Holder — 15 x 10 mm viewing area on each grating.
- Polarizing Filters — linear polarizers in 35 mm square frames.
- Color Filter Set — filters for colour transmission and absorption experiments.
- Introductory Optics System — double-sided 15 x 15 cm screen with 3 mm and 5 mm pinholes.
- Laboratory Spectrometer — vernier readings to 1 arcminute on a cast-iron base.
Browse the full Physics Lab range, the Light and Optics range, or all physics lab equipment.
