ME2 Mechanical Box, Forces
Product Code : SCL-PL-11938
ME2 Mechanical Box, Forces (SKU SCL-PL-11938) is a boxed set of materials for studying forces, selected for 13 experiments based on international curricula, from the principle of inertia to pulleys, inclined planes and energy conversion. It is aimed at secondary and senior secondary physics groups working at the bench. Schools, colleges, training institutes, tender contractors and distributors can obtain the box through Science Lab Supplies in Ambala, India, on one quotation with its required accessories.
Specifications
The ME2 forces box is broken down part by part in the table below. In short, pulleys, cords, a 2 N force gauge, slotted weights, a dynamic carriage and fixing parts sit in a foam insert inside a stackable case with a captive lid, while the rail, support and base are required accessories.
| Specification | Value |
|---|---|
| SKU | SCL-PL-11938 |
| Topic | Forces |
| Experiments | 13 |
| Case | Captive lid and built-in folding handle |
| Lid closure | Bayonet locking system; several boxes join into a stable stack |
| Release | Lift the central locking system |
| Insert | Foam insert with pre-formed cavities |
| Pulley with hook | 1 |
| Triple pulley | 1 |
| Friction block | 1 |
| Fixing nut | 1 |
| Cord, 50 cm | In case |
| Cord, 240 cm | In housing |
| Wire triangle | In housing |
| Rod coupling | 1 |
| Dynamic carriage | 1 |
| Threaded rod | With hook |
| Knurled screw | Black |
| Mounting pin | 1 |
| Weight support | 1 |
| Dynamometer support | 1 |
| Force gauge | 2 N |
| Support rod | 29 cm |
| Measuring tape | 2 m |
| Slotted weights | 50 g and 10 g |
| Spring bumper | 1 |
| Jumper | With screw |
| Required accessory | Universal rail, 1000 mm |
| Required accessory | Universal support |
| Profile base | Aluminium, 4 grooves for up to 4 rods on sliding T-nuts; bases can be connected |
| Literature | ME2 Student Workbook; Teacher’s manual, ME2 |
| Literature format | Electronic, for easy reproduction |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the ME2 Mechanical Box
The box turns the forces chapter into hands-on work: students can measure pulling forces with the 2 N gauge, compare pulley arrangements, test friction and resolve forces on a slope. Its 13 experiments match Newton's-laws and simple-machine topics in Class 9 and Class 11 physics and equivalent international syllabuses.
- Newton's first law, applications of inertia, and action and reaction, then accelerated motion on an Atwood Machine.
- Friction force and the force on a rope, with a Pair of Wooden Friction Blocks with Hooks for comparing surfaces.
- Forces on a fixed pulley, a moving pulley and a hoist.
- Parallelogram of forces and two inclined-plane experiments.
- Efficiency and conversion of mechanical energy.
Standard Scope of Supply
The box contains the parts listed in the table plus the ME2 student workbook and teacher's manual. The experiments also need two required accessories, a universal rail (1000 mm) and a universal support, and an aluminium profile base with four grooves for up to four rods on sliding T-nuts.
Packing, MOQ and Lead Time
A quotation can be drawn up for a single box or a class set, and it states packing, delivery time and price for that number. The rail, support and base, or the companion ME3+ box, can be priced alongside it.
Holding an Importer-Exporter Code as a registered exporter, Science Lab Supplies can ship to buyers in South Africa, Qatar, Sri Lanka, Vietnam, Malaysia and Peru. A school pricing the forces box can list it with the rail and support in the enquiry cart, ask about the contents on the contact page, or follow the lab tender page for a formal bid.
Frequently Asked Questions
How many experiments does the ME2 box cover?
Thirteen, from Newton's first law and friction through pulleys, a hoist and the parallelogram of forces to inclined planes, efficiency and conversion of mechanical energy.
Are teaching materials included?
Yes. An ME2 student workbook and a teacher's manual come with the box in electronic form, so they can be reproduced for every group in a class.
Who supplies the ME2 Mechanical Box, Forces?
The box, with its rail, support and base where needed, is quoted by Science Lab Supplies of Ambala, India. Schools, institutes and tender buyers can receive one combined quotation for the set and its required accessories.
What else is needed to run the experiments?
A universal rail of 1000 mm and a universal support are required accessories, together with the aluminium profile base whose four grooves hold up to four rods on sliding T-nuts.
Related Mechanics Sets
Forces are only one part of a mechanics course. These items continue into kinematics and energy or give further ways to show forces, friction and inclined planes with bench apparatus and spring balances, and each can be quoted with the ME2 box.
- ME3+ Mechanical Box — 20 kinematics, dynamics and energy experiments carried out in combination with the ME2 set.
- Complete Mechanics Kit — magnetic moments disc, 22-hole lever and four magnetic pulleys for board demonstrations.
- Set of Spring Force Meters with Different Ranges — spring force meters from 1 N to 20 N for gravity and tension measurement.
- Set of Dynamometers — tubular dual-scale spring balances from 2.5 N to 50 N with zero adjustment.
- Friction Demonstration Device (Tribometer) — 81.5 cm wooden plane set at 0–45 degrees, with a 200 g carriage and friction roller.
- Inclined Plane — hinged 600 mm plane adjustable from 0 to 45 degrees, with pulley, roller and mass pan.
