Lens Holder With Finished wood

Product Code : SCL-LAO-12113

Lens Holder With Finished wood (SKU SCL-LAO-12113) is a table-top optics stand with a sealed hardwood base and a plated metal clamp that holds lenses and mirrors from 38 to 50 mm in diameter upright on a fixed axis height. It supports focal-length and image-formation practicals in school and college physics, on a plain bench or an optical bench. Science Lab Supplies turns out these holders in its own facility at Plot 448, HSIIDC Industrial Area, Saha, Ambala, India, for direct supply to schools, colleges, tender contractors and distributors.

Specifications

Listed below is each specification of the wooden lens holder. In short, a seasoned hardwood base of about 100 x 50 x 25 mm carries an adjustable V-groove and a plated metal clamp with a tightening screw or spring guide, holding 38–50 mm optics at a constant centre height.

Applications and Experiments for the Wooden Lens Holder

The holder keeps a lens or mirror vertical and still while students move a screen or pin to find the image, so readings are not spoiled by the optic slipping. Because every holder shares the same axis height, several can be lined up for lens combinations.

• Class 10 science: focal length of a converging lens such as the Convex Lens 50mm on a table with a metre scale.
• Class 12 physics: lens-combination work with the Concave Optics Experiment Lens.
• Holding a spherical mirror such as the Concave Mirror (50 mm) for real-image mapping on a screen.
• Supporting optics in student science kits and STEM modules.

Tighten the clamp only lightly; too much pressure can chip glass. A slip of paper between screw and rim protects delicate optics.

Standard Scope of Supply

The order covers one lens holder with its finished wooden base and metal clamp assembly, plus a quick-reference setup sheet with basic alignment steps. Lenses, mirrors and screens are separate items and can be quoted together with the holders for a complete optics bench.

Packing, MOQ and Lead Time

A quotation can be raised for one holder or for as many as your benches need, since lens-combination work uses several per group. Science Lab Supplies states packing, delivery time and price for that quantity, and lenses or mirrors can be added.

With its Importer-Exporter Code, Science Lab Supplies is in a position to ship to buyers in Rwanda, South Africa, Qatar, Sri Lanka, Vietnam and Malaysia. Holder quantities may be sent through the contact page or the enquiry cart, and tendering institutions can refer to the lab tender page.

Frequently Asked Questions

What sizes of lens does it hold?
The adjustable V-groove holds lenses and mirrors from 38 mm to 50 mm in diameter, which covers common school lenses as well as the 50 mm lenses and mirrors in the Light and Optics range.

Can it hold mirrors as well as lenses?
Yes. The clamp grips spherical concave and convex mirrors as securely as lenses, provided the outer diameter of the mirror lies within the 38–50 mm range of the V-groove.

Will it work on a metal optical bench?
The flat base is designed for ordinary tables, but its metric footprint also fits the carriage blocks used on many school optical bench rails. Check your bench carriage size when ordering.

Is Science Lab Supplies the manufacturer or a trader?
Science Lab Supplies is the manufacturer. The wooden bases are shaped and finished, and the clamps fitted, at its Saha, Ambala workshop, so schools buy straight from the maker of the holder.

Related Holders, Lens Sets and Bench Items

These products include alternative holders, lens sets that fit a 38–50 mm stand, and the screen and bench used around it. Any of them can be combined with the wooden lens holder on one quotation for a school or college optics laboratory practical.

• Plastic Lens Holder V-shaped — molded HDPE frame with a central vertical alignment line.
• Wooden Lens Holder — takes optics up to 76 mm, index mark engraved at each end.
• Lens Kit with Stands and Storage Box — six lenses from −20 to +20 cm with stands.
• Glass Lens Demonstration — six 38 mm lenses with ground glass edges.
• Convex Mirror Optical — 50 mm crown glass mirror for virtual-image work.
• Laboratory White Viewing Screen — rigid ferrous steel base plate and thumb-screw collar.
• Optical Bench Ordinary Physics Lab — plated steel or anodised aluminium twin rails.

Browse the full Light and Optics range, the Physics Lab range for lens and mirror sets, or all physics lab equipment.
