Junior Circuit Board
Product Code : LSK-EAE-11120
Junior Circuit Board (SKU LSK-EAE-11120) is a single-sided, transparent plastic circuit board with a cell holder, switch, bulb holder, fuse and fan, on which school students build simple circuits to learn the basic principles of electricity and electronics. It works on 3 V DC. Science Lab Supplies manufactures it at its factory at Plot 448, HSIIDC Industrial Area, Saha, Ambala, India, and supplies schools, colleges, tender contractors and distributors directly.
Specifications
All stated details are in the table below. In short, the board has a transparent plastic base in single-sided format and works on 3 volts DC, with a cell holder, ON/OFF switch, connectors, fan, fuse and bulb holder for assembling basic circuits in a school laboratory.
| Specification | Value |
|---|---|
| SKU | LSK-EAE-11120 |
| Base | Transparent plastic |
| Board type | Single sided |
| Operating voltage | 3 V DC |
| Cell holder | Included |
| Switch | ON/OFF switch |
| Connectors | Included |
| Fan | Included |
| Fuse | Included |
| Bulb holder | Included |
| Intended users | Students in a school laboratory |
| Manufacturer | Science Lab Supplies, Saha, Ambala, Haryana |
| Country of origin | India |
Applications and Experiments for the Junior Circuit Board
The board lets younger students wire a cell, switch, fuse and load into a working circuit and see the result straight away as a lit bulb or a turning fan. It is practical school physics lab equipment in India for the electricity chapters of Class 6 to Class 10 science.
- Class 6 science: building a simple closed circuit and seeing how the ON/OFF switch opens and closes it.
- Class 7 science: observing the effects of current with the bulb and fan, and the role of the fuse.
- Testing conductors and insulators by placing samples between two connectors in the circuit.
- Further circuit practice with separate items such as the Circuits Kit Cell Holder and the Circuit Switch.
Use cells giving 3 V in total, as stated, and never connect the board to mains or a higher-voltage supply.
Standard Scope of Supply
Each Junior Circuit Board is supplied with its transparent single-sided base carrying a cell holder, ON/OFF switch, connectors, fan, fuse and bulb holder. Cells and a bulb can be added to the quotation if your school needs them, along with any other circuit items.
Packing, MOQ and Lead Time
A quotation can be made for one board or for a class set so each student group has its own. Science Lab Supplies details the packing, delivery time and price for that number of boards, and senior boards or other circuit items can be included on the same quotation.
As an exporter registered with an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Nepal, Bangladesh, Zambia, Rwanda, South Africa and Qatar. The business is registered under Udyam as a manufacturing enterprise (UDYAM-HR-01-0014546) and for GST (GSTIN 06ADEPJ0574F2ZU). Enquiries go through the contact page or the enquiry cart; the lab tender page covers tender procurement.
Frequently Asked Questions
What voltage does the Junior Circuit Board use?
It works on 3 volts DC, supplied through the cell holder on the board. Keep to this voltage and do not connect the board to mains power or a higher-voltage laboratory supply.
What components are on the board?
The board carries a cell holder, an ON/OFF switch, connectors, a fan, a fuse and a bulb holder, all on a transparent, single-sided plastic base, so students can follow the circuit layout as they work.
How is it different from the Senior Circuit Board?
The Senior Circuit Board also works on 3 V DC but adds a buzzer, rheostat, toggle switch and multimeter. The junior version keeps to the cell holder, ON/OFF switch, connectors, fan, fuse and bulb holder for first circuit lessons.
Is Science Lab Supplies the manufacturer or a trader?
Science Lab Supplies is the manufacturer, assembling the Junior Circuit Board at its factory in Saha, Ambala, India. Schools and distributors therefore receive their quotation directly from the maker.
Related Circuit Boards and Electricity Kits
These kits and holders cover the next steps after a first circuit: more components, series and parallel wiring, meters and spare parts. They come from the Electrical and Electronics and Physics Lab ranges, and any of them can be quoted together with the junior board.
- Ohms Law kit Apparatus — built-in 0–12 V DC supply with dual-range analog ammeter and voltmeter.
- Apparatus for Studying Circuits for Series and Parallel Connections — three bulbs, a rheostat and a magnetic board.
- EL1 Electricity Box, Electrical Circuits — materials for 17 electricity experiments, kept in a storage box.
- Cell Holder — gives 1.5, 3, 4.5 and 6 V DC with 4 mm sockets; takes 4 D-cells.
- Circuits Kit Bulb Holder — spare bulb holder mounted on a sturdy panel.
- Apparatus for Studying f.e.m. and Internal Battery and Battery Resistance — batteries, digital meters and a rheostat.
- Digital Ohms Law Apparatus 5 watts — 100 Ω, 5 W, with 0–10 V and 100 mA meter ranges.
Browse the full Electrical and Electronics range, the Physics Lab range for school electricity kits, or all physics lab equipment.
