Centrifugal Pump Test Set
Product Code : LSK-FM-10435
Centrifugal Pump Test Set (SKU LSK-FM-10435) is a compact, mobile and fully self-contained rig with which students find the characteristics of a centrifugal pump, watch and hear cavitation, and measure flow with a Venturi meter. It suits fluid machinery practicals in mechanical, civil and chemical engineering degrees and diplomas. Production takes place at Plot 448, HSIIDC Industrial Area, Saha, Ambala, India, where Science Lab Supplies manufactures the rig and prices it directly for institutions, tender contractors and distributors.
Specifications
Row by row, the table covers the drive, instruments and water circuit of this pump test set. In short, a bearing-mounted motor under electronic Motor Drive control turns the pump, a load cell and speed sensor feed a display that calculates true shaft power, and the Venturi differential pressure gives the flow rate.
| Specification | Value |
|---|---|
| SKU | LSK-FM-10435 |
| Format | Compact, mobile, fully self-contained |
| Pump | Centrifugal, with transparent window to view the impeller and cavitation |
| Motor | Mounted in bearings |
| Speed control | Electronic Motor Drive |
| Torque measurement | Strain gauge load cell |
| Speed measurement | Speed sensor |
| Motor Drive display | Speed and torque; true shaft power calculated automatically |
| Instrument mounting | Instrument and control modules in a frame above and behind the pump |
| Flow measurement | Differential pressure across a Venturi meter |
| Valves | Adjustable inlet and delivery valves |
| Water circuit | Integral reservoir, valve and filter, inlet valve, pump, delivery valve, Venturi, return to reservoir |
| Water use | Self-contained supply keeps consumption to a minimum |
| Instrumentation | Analogue and digital, usable at the same time |
| Digital Display | Connects to the frame-mounted Versatile Data Acquisition System |
| Option | Stroboscope |
| Manufacturer | Science Lab Supplies, Saha, Ambala, Haryana |
| Country of origin | India |
Applications and Experiments for the Centrifugal Pump Test Set
The set is used to plot centrifugal pump characteristics under different operating conditions, created with the adjustable inlet and delivery valves, and to show cavitation through the pump window. It also teaches Venturi flow measurement and lets students compare analogue and digital pressure readings side by side.
- B.Tech / B.E. fluid machinery lab: head, power and efficiency against flow.
- Cavitation study: throttling the inlet until vapour bubbles form at the impeller.
- Venturi theory, extended with the pressure tappings along the convergent-divergent passage of the Bernoulli's Theorem apparatus and the separate Venturi Flowmeter for flow meter calibration work.
- Diploma and TVET pump courses: effect of speed on performance.
Standard Scope of Supply
The test set comes as one self-contained unit: centrifugal pump with viewing window, bearing-mounted motor, integral reservoir, valves and filter, Venturi meter, and the instrument frame with Motor Drive and display. The stroboscope is optional; the analogue or digital pressure display and data acquisition option are confirmed item by item on the quotation.
Packing, MOQ and Lead Time
Whether you need a single test set or several for a fluid mechanics lab, ask and the quotation will list packing, delivery time and price for exactly that quantity. Other engineering lab equipment in India from this range can be priced alongside it.
Science Lab Supplies holds an Importer-Exporter Code and can ship to buyers in Saudi Arabia, Oman, the Philippines, Nepal, Bangladesh and Zambia. Pump-lab enquiries are welcome on the contact page; you can also build a list in the enquiry cart or check the lab tender page before a public bid.
Frequently Asked Questions
Can students see cavitation on this rig?
Yes. The pump has a transparent window, so students see the impeller turning and the vapour bubbles that form at cavitation, and they can hear it. An optional stroboscope makes the effect easier to see.
How is shaft power measured?
A strain gauge load cell measures the driving torque and a sensor measures pump speed. The Motor Drive display shows both readings and automatically calculates the true shaft power for each test point.
Does the test set need a mains water supply?
No. Water circulates from the integral reservoir through the pump and Venturi meter and back again, which keeps water consumption to a minimum.
Is Science Lab Supplies the manufacturer or a trader?
This pump rig leaves the Science Lab Supplies plant in Saha, Ambala, India, built as one self-contained unit, so the company is its manufacturer and the price you receive is the maker's own.
