Lathe Tool
Product Code : LSK-TOMLE-10629
Lathe Tool (SKU LSK-TOMLE-10629) is a two-component, strain-gauge lathe tool dynamometer that measures the vertical and horizontal forces on the cutting tool during orthogonal turning. Students vary speed, depth of cut and feed and watch how both forces change. It is aimed at metal-cutting labs in engineering colleges and polytechnics. Orders from institutions, tender contractors and distributors are handled by Science Lab Supplies from its base in Ambala, India.
Specifications
Below, each specification of the two-component lathe dynamometer has its own row. In short, it has a strain-gauged mechanical sensing unit that doubles as the tool holder and a control panel housing the digital force indicator; the holder mounts on the cross slide once the swivel base and compound slide are removed.
| Specification | Value |
|---|---|
| SKU | LSK-TOMLE-10629 |
| Type | Two-component strain-gauge lathe tool dynamometer |
| Cutting process | Orthogonal cutting on a lathe |
| Forces measured | Vertical and horizontal cutting forces, read simultaneously |
| Range | 0–500 kg |
| Sensing unit | Mechanical sensing unit / tool holder with strain gauges |
| Mounting | On top of the cross slide after removing the swivel base and compound slide |
| Cutting tool | H.S.S. tool, ½ inch (12.7 mm) size |
| Indicator | Compact digital force indicator in a control panel |
| Panel fittings | Balancing potentiometers, connecting cable, switches, fuses, polycarbonate front plate |
| Signal system | Sensitive transducing and amplifying system |
| Construction | Rigid |
| Variables studied | Speed, depth of cut and feed |
| Cutting fluid | Can be used during operation |
| Other model | Three-component lathe tool dynamometer available |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Lathe Tool Dynamometer
The dynamometer is used to measure cutting forces in turning and to relate them to the chosen speed, feed and depth of cut. It is a standard piece of the metal-cutting or machine-tool laboratory in mechanical and production engineering courses and supports practical sessions for vocational training equipment programmes in turning.
- B.Tech / B.E. mechanical and production engineering: cutting forces in orthogonal turning.
- Diploma mechanical engineering: effect of feed and depth of cut on tool forces.
- Comparing dry cutting with cutting under coolant.
- ITI turner and machinist training: instructor demonstrations.
Mounting needs a lathe whose swivel base and compound slide can be taken off. A Center Lathe Machine can go on the same enquiry, and a Strain Gauge Kit lets students bond gauges like those inside the sensing unit.
Standard Scope of Supply
Supply covers the mechanical sensing unit (tool holder) with strain gauges, an H.S.S. tool of ½ inch size, and the control panel with digital force indicator, balancing potentiometers, connecting cable, switches, fuses and front plate. The lathe itself is not included.
Packing, MOQ and Lead Time
Ask for a quotation for one dynamometer or for a set to equip several lathes; the reply lists packing, delivery time and price for exactly that quantity. The grinding, drilling and milling dynamometers from this range can be priced on the same quotation.
Science Lab Supplies holds an Importer-Exporter Code as a registered exporter and can ship to buyers in Ethiopia, Tanzania, Uganda, the UAE, Saudi Arabia and Oman. Questions about mounting or quantities can be raised on the contact page; to price the dynamometer with other items, drop it into the enquiry cart, and see the lab tender page if your institution is issuing a tender.
Frequently Asked Questions
Which forces does the Lathe Tool measure?
It measures the vertical and horizontal forces acting on the tool during orthogonal cutting, each up to 500 kg. Both values appear at the same time on the digital force indicator in the control panel.
How is it fitted to the lathe?
The swivel base and compound slide are removed and the sensing unit, which acts as the tool holder, is mounted on top of the cross slide. The indicator panel connects to it by cable.
Is a three-component version available?
Yes, a three-component lathe tool dynamometer is also available. Mention it in your enquiry and it can be quoted alongside or instead of this two-component model.
Who supplies this dynamometer?
The supplier is Science Lab Supplies, a TVET lab equipment supplier working out of Ambala, India. It prepares quotations directly for colleges and training institutes, and for tender contractors and distributors buying on their behalf.
