Motorized Compression/Tension Machine
Product Code : LSK-CL-10584
Motorized Compression/Tension Machine (SKU LSK-CL-10584) is a motor-driven testing frame for compression tests up to 2000 kN and tensile tests up to 500 kN. Civil engineering and construction-materials laboratories use it to load specimens to failure and read the force on its two-channel digital indicator. Engineering colleges, polytechnics, TVET institutes, tender contractors and distributors can have it quoted and delivered by Science Lab Supplies, which operates from Ambala, India.
Specifications
Every load, stroke and accessory figure for the 2000 kN frame sits in its own row below. In short, the frame has a 100 mm piston stroke and a 280 mm span between its columns, with manual pacer-guided rate control, a two-channel universal digital indicator and a remote button switch for the readout units.
| Specification | Value |
|---|---|
| SKU | LSK-CL-10584 |
| Use | Compression and tension tests |
| Maximum compression load | 2000 kN |
| Compression reading | 0.1 kN divisions |
| Maximum tensile load | 500 kN |
| Tensile reading | 0.01 kN divisions |
| Piston stroke | 100 mm |
| Span between columns | 280 mm |
| Rate control | Manual regulation of load / tensile rate with pacer |
| Indicator | Two-channel universal digital indicator for dynamometers and load cells |
| Load cell | Compression load cell, 2000 kN capacity |
| Load cell calibration | Factory calibrated |
| Remote control | Remote button switch for readout units |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Compression/Tension Machine
The machine is used to find the compressive strength of concrete and other construction specimens and to run tension tests within its 500 kN limit. It suits concrete technology and building-materials practicals in B.Tech and diploma civil engineering, and materials-testing modules in TVET construction courses.
- B.Tech / B.E. civil engineering: compressive strength of hardened concrete cast from batches made in the Laboratory Concrete Mixer.
- Diploma civil engineering: building-materials testing, after each batch is checked on the Slump Test Apparatus.
- Tension tests on specimens within the 500 kN tensile rating.
- TVET construction and materials-testing courses: supervised load-to-failure demonstrations.
Specimens under high load can fail suddenly; keep trainees clear of the loading zone and test only under supervision.
Standard Scope of Supply
The machine is supplied with a two-channel universal digital indicator for dynamometers and load cells, a 2000 kN compression load cell with factory calibration, and a remote button switch for the readout units. Specimen moulds and any other fixtures your test programme needs are quoted separately.
Packing, MOQ and Lead Time
You can request a price for one machine or for several testing stations, and every quotation sets out the packing, delivery time and price for the quantity you name. Specimen preparation equipment such as the laboratory concrete mixer can be added, which suits buyers comparing engineering lab equipment in India.
As a registered exporter under an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Ghana, Ethiopia, Tanzania, Uganda, the UAE and Saudi Arabia. Science Lab Supplies is registered for GST (GSTIN 06ADEPJ0574F2ZU). To get this frame priced, outline your test programme on the contact page, save it to the enquiry cart with any companion items, or use the lab tender page for a bid with formal specifications.
Frequently Asked Questions
What loads can this machine apply?
It applies up to 2000 kN in compression, read in 0.1 kN divisions, and up to 500 kN in tension, read in 0.01 kN divisions. The piston stroke is 100 mm and the span between columns is 280 mm.
How is the loading rate controlled?
The load or tensile rate is regulated manually, with a pacer helping the operator hold a steady rate while the two-channel indicator shows the rising force.
Who supplies the Motorized Compression/Tension Machine?
Science Lab Supplies is the supplying company, sending the machine from Ambala, India. It quotes colleges and training institutes directly and gives tender contractors and distributors the same detailed, item-wise offer.
Can it be quoted against a tender?
Yes. Send the tender specification, quantity and delivery point, and an item-wise quotation based on the specification table above will follow, with any mixer, slump cone or other concrete equipment in the tender priced alongside.
Related Concrete and Materials Testing Equipment
Compression testing is the last step in a chain of concrete, aggregate and materials tests. These items from the Concrete Laboratory and Material Testing ranges cover rock strength, impact, durability, abrasion and bench-scale tension and compression, so a complete materials lab can be quoted together.
- Digital Point Load Tester — 56 kN load frame with a manual hydraulic jack for rock cores up to 101.6 mm.
- Impact Testing Machine — pendulum on antifriction bearings with upper Charpy and lower Izod start positions.
- Concrete Cover Meter — reads concrete cover to 0.1 mm resolution and runs 20 hours on battery.
- Water Permeability Test Kit — pressure chamber with a 0–1.5 bar gauge and built-in micrometer gauge.
- Los Angeles Abrasion Machine — automatic counter preset to drum revolutions or working time.
- Universal Testing Machine — four-column steel frame and hydraulic ram, compressing above the platform and pulling below it.
- Bench Top Tensile Testing Machine — hand-driven worm-and-wheel loading of metal specimens up to 20 kN.
Browse the full Concrete Laboratory range, the Material Testing Equipment range for tensile, hardness and impact apparatus, or all TVET lab equipment.
