Block Making Machine
Product Code : LSK-WT-10540
Block Making Machine (SKU LSK-WT-10540) is a hydraulic compacting press with its own pan mixer and conveyor that forms bricks four at a time on a PVC pallet. Vocational colleges use it to give masonry and building-construction trainees hands-on practice in brick production. Science Lab Supplies supplies it from Ambala, India to TVET institutes, polytechnics, tender contractors and distributors.
Specifications
The machine presses four bricks per stroke with 100 ton hydraulic compaction on a 600 x 300 x 25 mm PVC pallet. A pan mixer driven by a 7.5 HP three-phase motor prepares the mix and a 20-foot conveyor feeds it. Total power required is 31.5 HP, and the rated output is 1680 bricks per hour.
| Parameter | Value |
|---|---|
| SKU | LSK-WT-10540 |
| System | Hydraulic power compacting, 100 ton |
| Bricks per stroke | 4 (one pallet) |
| Strokes per hour | 420 (7 per minute) |
| Production capacity | 1680 bricks per hour (rated) |
| Brick size | 230 x 110 x 75 mm, with frog |
| Pallet | PVC, 600 x 300 x 25 mm |
| Conveyor length | 20 ft (about 6.1 m) |
| Total power required | 31.5 HP |
| Pan mixer | Bottom plate 10 mm; side wall 5 mm, 500 mm high; motor 7.5 HP, 1480 rpm, 3 phase |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Block Making Machine
The machine is used in TVET and ITI construction workshops to show how mixing, hydraulic compaction and pallet handling combine into one brick production line, and in civil engineering diploma labs to make bricks for size and strength checks. It suits institutes that want vocational training equipment linked to real production.
- Masonry and building-construction trades (TVET, ITI/NSQF): producing uniform bricks for bricklaying practice.
- Civil engineering diploma and B.Tech building-materials labs: brick specimens for dimension and compressive-strength tests.
- Plant operation modules: running mixer, conveyor and press as one line under supervision, with power isolated before cleaning.
Standard Scope of Supply
The Block Making Machine is supplied as the hydraulic power-compacting press, the pan mixer with its 7.5 HP motor and the 20-foot conveyor, as set out in the specification above. The number of PVC pallets and any optional accessories are stated on the quotation, so please confirm them when ordering.
Packing, MOQ and Lead Time
You can ask for a quotation for a single machine or for a complete construction workshop, and each quotation states the packing, delivery time and price for that quantity. Mixers, vibrators and other site tools from the same range can go on one quotation, keeping TVET workshop equipment purchasing simple.
As a registered exporter with an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Ghana, Ethiopia, Tanzania, Uganda, the UAE and Saudi Arabia. Science Lab Supplies is registered for GST (GSTIN 06ADEPJ0574F2ZU). Enquire via the contact page or enquiry cart; see also the lab tender page.
Frequently Asked Questions
What output does the Block Making Machine give?
It is rated at 1680 bricks per hour: four bricks per stroke at 420 strokes an hour, or seven strokes a minute. Each brick measures 230 x 110 x 75 mm with a frog.
What power supply does the machine need?
The complete line needs 31.5 HP in total, and the pan mixer motor is a three-phase unit, so the workshop needs a three-phase supply sized for the full load.
Who supplies the Block Making Machine?
Science Lab Supplies supplies it from Ambala, India, and can quote it with other construction tools for TVET institutes, polytechnics, contractors and distributors.
Can it be quoted for a TVET tender?
Yes. Send the quantity, delivery location and tender specification through the contact page for an item-wise quotation against the specification above.
