Apparatus for Distilling Liquids
Product Code : SCL-CL-11448
Apparatus for Distilling Liquids (SKU SCL-CL-11448) is a complete simple-distillation set: a liquid is boiled in a side-arm flask, its vapour is cooled in a Liebig condenser and the distillate is collected in a beaker. Teachers use it to purify water or separate a liquid from dissolved solids. The set is supplied by Science Lab Supplies from Ambala, India, for schools, colleges, training institutes, distributors and tender contractors.
Specifications
The set is built around a 250 ml distillation flask with a side arm, closed by a holed rubber stopper that carries a 0–100 °C thermometer. Vapour passes into a 300 mm straight (Liebig) condenser held on two metal-based stands with support rods, and the distillate runs into a 250 ml beaker.
| Parameter | Value |
|---|---|
| SKU | SCL-CL-11448 |
| Distillation flask | 250 ml, side arm, holed rubber stopper |
| Condenser | Straight (Liebig), 300 mm |
| Thermometer | 0–100 °C |
| Supports | 2 metal-base stands with rods; 2 metal holders; 200 mm metal support piece |
| Receiver | 250 ml beaker |
| Heating mesh | 150 x 150 mm, listed as asbestos mesh |
| Tubing | Rubber, 6 mm diameter |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Apparatus for Distilling Liquids
This distillation set shows how a mixture is separated by boiling and condensation, and how the temperature stays steady while a pure liquid distils over. It supports separation-of-mixtures lessons in secondary school and the purification topics met in Class 11 and B.Sc. chemistry practicals.
- NCERT Class 6 and Class 9 science: obtaining pure water from salt water by distillation.
- Class 11 chemistry: distillation as a way to purify organic liquids.
- B.Sc. practicals: recording the steady boiling temperature of a liquid during distillation.
- Teacher-training labs: safe assembly of flask, condenser and receiver.
Standard Scope of Supply
One set comprises two stands with metal bases and rods, the 250 ml side-arm flask with holed rubber stopper, the 300 mm Liebig condenser, a 200 mm metal support piece, a 250 ml beaker, a 150 x 150 mm mesh, a 0–100 °C thermometer, 6 mm rubber tubing and two metal holders.
Packing, MOQ and Lead Time
If you are sourcing laboratory distillation apparatus in India, quotations can cover one set or enough for a whole class. Each quotation shows the packing, the delivery time and the price for the quantity requested, and spare condensers, flasks or thermometers can be listed on it as separate lines.
As a registered exporter with an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Oman, the Philippines, Nepal, Bangladesh, Zambia and Rwanda. Science Lab Supplies is registered for GST (GSTIN 06ADEPJ0574F2ZU). Send your list through the contact page, add items to the enquiry cart, or read about tender quotations on the lab tender page.
Frequently Asked Questions
Is the heating mesh a safety concern?
The original specification lists the 150 x 150 mm mesh as asbestos. Asbestos fibres are a health hazard if the mesh is damaged, so check your institution's rules and ask us to confirm the mesh type on your quotation.
Who supplies the Apparatus for Distilling Liquids?
Science Lab Supplies, based in Ambala, India, supplies this set to schools, colleges and training institutes, and quotes distributors and tender contractors for larger quantities.
Can the thermometer be used for liquids boiling above 100 °C?
No. The thermometer reads 0–100 °C, so it suits water and lower-boiling liquids. For higher-boiling liquids, request a wider-range thermometer on the same quotation.
Related Distillation Glassware
These four items from the Chemistry Lab range are the parts most often replaced or added when a distillation set is in regular class use: a spare condenser and flask, extra thermometers and rubber tubing for the cooling water. All of them can go on the same quotation.
- Straight Cooler (Condenser) — spare straight condenser.
- Distillation Pot with Side Funnel 250ml — replacement side-arm flask.
- Laboratory Thermometers — extra thermometers for the vapour reading.
- Rubber Tube (Laboratory) — tubing for condenser water.
Browse the full Chemistry Lab range or all school lab equipment.
