Chain Pipe Cutter

Chain Pipe Cutter

Product Code : LSK-PWI-10536

The Chain Pipe Cutter is a pipe-cutting tool for plumbing training: a chain fitted with cutting wheels is wrapped round the pipe and tightened until the pipe parts along the line. It takes pipe up to 4-9/16 in (about 116 mm) and measures 12 in (about 305 mm) overall.

Specifications of the Chain Pipe Cutter

SpecificationValue
Tool typeChain pipe cutter
Pipe capacity4-9/16 in (about 116 mm)
Overall length12 in (about 305 mm)
Supplied byScience Lab Supplies, Ambala, India

Pipe Cutting Tasks in the Plumbing Workshop

Trainees mark the cut, wrap the chain square round the pipe on the mark and tighten it in steady steps. The wheels score the pipe all the way round until it breaks on the line. Because the cutter works round the pipe, it can also cut pipe already fixed close to a wall or lying in a trench.

  • Cutting to length: cut drain or soil pipe to the measured length for a stack, branch or offset, then check that the end is square.
  • Comparing methods: cut the same pipe with a Hacksaw Frame and compare squareness, time taken and the burr left on the end.
  • Finishing the end: take off sharp edges and burrs with a Round File before a coupling is fitted.
  • Fitting practice: join the cut lengths with couplings and check the run for line and level.

Wear eye protection and gloves, as brittle pipe can splinter, and support both sides of the cut so the off-cut does not drop.

Frequently Asked Questions

Which pipe sizes can the cutter take?
Its pipe capacity is 4-9/16 in, about 116 mm. Before ordering, check the outside diameter of the pipes used in the training bay rather than their nominal bore, as the two often differ.

Which pipe materials is a chain cutter normally used on?
Chain cutters are mainly used on brittle pipe such as cast iron soil pipe, clay and cement pipe, which they part by pressing the wheels in until the pipe snaps. For copper or plastic pipe a wheel-type tube cutter or a hacksaw is the usual choice.

Which spares do training centres keep for a chain cutter?
The cutting wheels on the chain wear with use and can chip on hard pipe, so workshops usually keep a spare chain or set of wheels, plus a file and a wire brush for cleaning cut ends and the chain after each class.

Why must the chain sit square to the pipe?
The pipe breaks along the line the wheels score. If the chain is wrapped at an angle, the cut follows that angle and the end will not seat properly in a coupling, so the joint may leak or need recutting.

Why is the pipe scored a little at a time before it breaks?
Small, even tightening steps let the wheels mark a clean groove all round. Turning the cutter slightly between steps and keeping the wheels in the same groove gives a straight break instead of a crushed or jagged end.

Related Pipe Working and Finishing Tools

This cutter belongs to the Plumbing Workshop Instrument group, which falls under TVET Lab Equipments for trade training centres.

Trade schools in Egypt, Iraq, Nigeria, Kenya, Ghana and Ethiopia can import the cutter from Science Lab Supplies, which has an Importer-Exporter Code for overseas orders. A quotation can be requested from the contact page or by adding the tool to the enquiry cart.
