Dimension Saw Machine
Product Code : LSK-WWPT-10722
Dimension Saw Machine (SKU LSK-WWPT-10722) is a sliding-table panel saw that cuts boards and sheet material to exact size, with a scoring blade to prevent chipping on faced panels. Furniture and carpentry workshops in ITI, polytechnic and TVET institutes use it to teach accurate rip and cross cuts. Science Lab Supplies supplies it from Ambala, India to training institutes, tender contractors and distributors of vocational training equipment.
Specifications
A heavy saw carriage sits in a large cast-iron cradle and carries a 3000 x 320 mm easy-glide sliding table. Handwheels set blade height and tilt, a simple index shows the tilt angle, the scorer is adjusted manually, and a quick-release cross-cut fence and overhead guard complete the machine.
| Parameter | Value |
|---|---|
| SKU | LSK-WWPT-10722 |
| Sliding table | 3000 x 320 mm |
| Cross-cut capacity | 3000 (as listed) |
| Rip width, blade to fence | 1250 mm |
| Main saw blade | 300 mm (250–300 mm), 30 mm spindle |
| Height of cut | 80 mm with 300 mm blade |
| Main spindle speed | 4000/6000 rpm |
| Blade tilt | 0–45° |
| Main motor | 3 kW |
| Scoring saw | 120 mm blade, 20 mm size as listed, 7000–8000 rpm, 1.1 kW motor |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Dimension Saw
The dimension saw is the main sizing machine in a furniture or cabinet-making shop. The long sliding table carries full boards past the blade, so trainees in ITI carpentry and furniture trades, TVET joinery modules and polytechnic workshops can learn square, repeatable cuts on panels and solid timber.
- Cross-cutting and ripping panels to a cutting list.
- Chip-free cuts on laminated board using the scoring blade.
- Bevel cuts with the blade tilted up to 45 degrees.
- Teaching blade height setting, fence use and guarding on a panel saw.
This is a powered saw with an exposed blade: use it only under an instructor, with the overhead guard fitted, push sticks for narrow pieces and dust extraction running.
Standard Scope of Supply
The Dimension Saw Machine is supplied as a single unit with the sliding table, cross-cut fence, saw carriage, main and scoring saw drives and overhead guard described above. Spare blades, a dust collector and other optional accessories are listed on the quotation if requested.
Packing, MOQ and Lead Time
A quotation can be prepared for one saw or for several machines in a new furniture workshop. It will state the packing, delivery time and price for your quantity, and other TVET workshop equipment such as planers and dust collectors can be added to the same document.
As a registered exporter with an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Oman, the Philippines, Nepal, Bangladesh, Zambia and Rwanda. Use the contact page or enquiry cart, and see the lab tender page for institutional orders.
Frequently Asked Questions
What does the scoring blade do?
The small 120 mm scoring blade runs ahead of the main blade and cuts a shallow groove in the underside of the panel, so laminated or veneered boards do not chip as the main 300 mm blade passes through.
How wide can the machine rip?
The distance between saw blade and rip fence is 1250 mm, and the sliding table is 3000 mm long, so full-size sheets can be broken down into parts.
Who supplies the Dimension Saw Machine?
Science Lab Supplies supplies it from Ambala, India, to ITIs, polytechnics, TVET centres, tender contractors and distributors, quoted together with other workshop machines.
What power supply does it need?
The main motor is 3 kW and the scoring motor 1.1 kW. The supply voltage and phase are not given in this listing, so state your mains supply in the enquiry and the quotation will confirm it.
